ASUS
ASUS ROG STRIX Z590-E GAMING WIFI
Intel ® Z590 LGA 1200 ATX motherboard with PCIe 4.0, 14+2 teamed power stages, Two-Way AI Noise Cancelation, AI Overclocking, AI Cooling, AI Networking, WiFi 6E (802.11ax), dual Intel ® 2.5 Gb Ethernet, four M.2 slots with heatsinks, USB 3.2 Gen 2x2 USB Type-C ® , SATA and Aura Sync RGB lighting
Product image gallery
About this product
Details & use
Intel ® Z590 LGA 1200 ATX motherboard with PCIe 4.0, 14+2 teamed power stages, Two-Way AI Noise Cancelation, AI Overclocking, AI Cooling, AI Networking, WiFi 6E (802.11ax), dual Intel ® 2.5 Gb Ethernet, four M.2 slots with heatsinks, USB 3.2 Gen 2x2 USB Type-C ® , SATA and Aura Sync RGB lighting
Technical specifications are provided by Taba Trading Expansion. Products are sold exclusively through authorized dealers. For availability, pricing, and orders, please contact the sales team.
Photo 1/8
Specifications
Technical specs
Motherboard
- Clear CMOS
- Yes
- Form factor
- ATX
- Chipset
- Intel Z590
- Platform
- Intel
- BIOS
- 256 Mb Flash ROM, UEFI AMI BIOS
- Operating system
- Windows® 10 64-bit, Windows® 11 64-bit
- Series
- ROG STRIX
Processor
- CPU power connector
- یک pcs 4 پین, یک pcs 8 پین
- CPU power circuit
- 14+2 فاز
- CPU generation
- نسل یازدهم, نسل دهم
- Socket
- Intel Core i3/i5/i7/i9 , Pentium Gold and Celeron
- CPU socket
- LGA-1200
Memory
- Memory type
- DDR4
- RAM slots
- 4 pcs
- Memory
- supports memory RAM DDR4 با up to frequency 5333 MHz
- RAM capacity
- 128 GB
Expansion Slots
- PCIe x1
- No
- PCIe x4
- No
- PCIe x16
- یک slot PCIe 3.0 x16, دو slot PCIe 4.0 X16
Storage
- M.2
- دو pcs PCIe 3.0, دو pcs PCIe 4.0
- SATA III
- 6 pcs
I/O & Connectivity
- Digital audio
- OPTICAL S/PDIF
- USB 3.0
- No
- USB 3.2
- 8 pcs
- HDMI
- Yes
- USB 3.1
- No
- USB 2.0
- 2 PCS
- DisplayPort
- Yes
- Audio channels
- 7.1 کانال
- Audio
- - ALC4080 + Savitech SV3H712 AMP
- Bluetooth
- نسخه 5.2
- Communication protocols
- supports frequency 2.4/5/6 گیگاهرتز, 802.11a/b/g/n/ac/ax
- Thunderbolt
- به صورت کانکتور connectivity
- LAN
- Intel 2.5Gb Ethernet port
- Wi-Fi
- Intel Wi-Fi 6E
Power
- Power switch
- No
Other specs
- LED color
- ARGB
- Debug display
- Yes
- 3.5 mm jack
- 5 pcs
- PCI
- No
- Multi-GPU support
- Supports NVIDIA® 2-Way SLI® Technology
- DVI
- No
- D-Sub
- No
- Intel Optane
- Yes
- Configure
- دو کاناله
Key points
Why this product?
The standout features that make this model a strong choice for professional builds.
LED color: ARGB
Debug display: Yes
Power switch: No
Digital audio: OPTICAL S/PDIF
