ASUS TUF GAMING Z590-PLUS

Intel® Z590 (LGA 1200) ATX gaming motherboard with 16 DrMOS power stages, PCIe® 4.0, three M.2 slots, Intel® 2.5 Gb Ethernet, HDMI®, DisplayPort™, USB 3.2 Gen 2x2 Type-C®, SATA 6 Gbps, front panel USB 3.2 Gen 1 Type C®, Thunderbolt™ 4 support and Aura Sync RGB lighting

MotherboardASUSOfficial Taba warranty

← Prev Next →

About this product

Details & use

Technical specifications are provided by Taba Trading Expansion. Products are sold exclusively through authorized dealers. For availability, pricing, and orders, please contact the sales team.

Photo 1/6

Specifications

Technical specs

Motherboard

BIOS: 192 (128+64) Mb Flash ROM, UEFI AMI BIOS
Operating system: Windows® 11 64-bit, Windows® 10 64-bit
Chipset: Intel Z590
Platform: Intel
Clear CMOS: Yes
Form factor: ATX
Series: TUF Gaming

Processor

CPU power connector: یک pcs 8 پین, یک pcs 4 پین
CPU power circuit: 14+2 فاز
CPU generation: نسل یازدهم, نسل دهم
Socket: Intel Core i3/i5/i7/i9 , Pentium Gold and Celeron
CPU socket: LGA-1200

Memory

Memory: supports memory RAM DDR4 با up to frequency 5133 MHz
RAM capacity: 128 GB
Memory type: DDR4
RAM slots: 4 pcs

Expansion Slots

PCIe x16: یک slot PCIe 4.0 x16, یک slot PCIe 3.0 x16
PCIe x1: 2 PCS
PCIe x4: No

Storage

SATA III: 6 pcs
M.2: یک pcs PCIe 4.0, دو pcs PCIe 3.0

I/O & Connectivity

DisplayPort: Yes
Thunderbolt: به صورت کانکتور connectivity
Audio: Realtek® ALC S1200A 7.1 Surround Sound High Definition Audio CODEC
Audio channels: 7.1 کانال
LAN: Intel 2.5Gb Ethernet port
Bluetooth: No
Wi-Fi: No
Digital audio: OPTICAL S/PDIF
HDMI: Yes
USB 3.2: 5 pcs
USB 3.1: No
USB 3.0: No
USB 2.0: 2 PCS

Other specs

DVI: No
D-Sub: No
LED color: ARGB
Debug display: No
3.5 mm jack: 5 pcs
Intel Optane: Yes
Multi-GPU support: No
PCI: No
Configure: دو کاناله
