ASUS TUF GAMING Z590-PLUS WIFI
Intel® Z590 (LGA 1200) ATX gaming motherboard with 16 DrMOS power stages, PCIe® 4.0, three M.2 slots, Intel® WiFi 6 and 2.5 Gb Ethernet, HDMI®, DisplayPort™, USB 3.2 Gen 2x2 Type-C®, SATA 6 Gbps, front panel USB 3.2 Gen 1 Type C®, Thunderbolt™ 4 support and Aura Sync RGB lighting
Product image gallery
About this product
Details & use
Intel® Z590 (LGA 1200) ATX gaming motherboard with 16 DrMOS power stages, PCIe® 4.0, three M.2 slots, Intel® WiFi 6 and 2.5 Gb Ethernet, HDMI®, DisplayPort™, USB 3.2 Gen 2x2 Type-C®, SATA 6 Gbps, front panel USB 3.2 Gen 1 Type C®, Thunderbolt™ 4 support and Aura Sync RGB lighting
Technical specifications are provided by Taba Trading Expansion. Products are sold exclusively through authorized dealers. For availability, pricing, and orders, please contact the sales team.
Photo 1/8
Specifications
Technical specs
Motherboard
- Operating system
- Windows® 10 64-bit, Windows® 11 64-bit
- BIOS
- 192 (128+64) Mb Flash ROM, UEFI AMI BIOS
- Clear CMOS
- Yes
- Chipset
- Intel Z590
- Platform
- Intel
- Form factor
- ATX
- Series
- TUF Gaming
Processor
- Socket
- Intel Core i3/i5/i7/i9 , Pentium Gold and Celeron
- CPU generation
- نسل دهم, نسل یازدهم
- CPU power circuit
- 14+2 فاز
- CPU power connector
- یک pcs 4 پین, یک pcs 8 پین
- CPU socket
- LGA-1200
Memory
- RAM slots
- 4 pcs
- Memory type
- DDR4
- RAM capacity
- 128 GB
- Memory
- supports memory RAM DDR4 با up to frequency 5133 MHz
Expansion Slots
- PCIe x16
- یک slot PCIe 3.0 x16, یک slot PCIe 4.0 x16
- PCIe x1
- 2 PCS
- PCIe x4
- No
Storage
- M.2
- دو pcs PCIe 3.0, چهار pcs PCIe 4.0
- SATA III
- 6 pcs
I/O & Connectivity
- USB 3.2
- 5 pcs
- USB 3.0
- No
- USB 2.0
- 2 PCS
- DisplayPort
- Yes
- Thunderbolt
- به صورت کانکتور connectivity
- Audio
- Realtek® ALC S1200A 7.1 Surround Sound High Definition Audio CODEC
- Communication protocols
- 802.11a/b/g/n/ac/ax
- Wi-Fi
- Intel Wi-Fi 6
- LAN
- Intel 2.5Gb Ethernet port
- Audio channels
- 7.1 کانال
- Digital audio
- OPTICAL S/PDIF
- USB 3.1
- No
- HDMI
- Yes
Other specs
- LED color
- ARGB
- Configure
- دو کاناله
- Multi-GPU support
- No
- Intel Optane
- Yes
- DVI
- No
- 3.5 mm jack
- 5 pcs
- Debug display
- No
- D-Sub
- No
- PCI
- No
Key points
Why this product?
The standout features that make this model a strong choice for professional builds.
Operating system: Windows® 10 64-bit
BIOS: 192 (128+64) Mb Flash ROM, UEFI AMI BIOS
LED color: ARGB
Clear CMOS: Yes
