SilverStone
SilverStone ST85F-PT
￭ Compact design with a depth of 140mm for easy integration ￭ High efficiency with 80 PLUS Platinum certification ￭ 100% modular cables ￭ 24/7 continuous power output with 40℃ operating temperature ￭ Class-leading single +12V rail ￭ Strict ±3% voltage regulation and low ripple & noise ￭ Ultra silent 120mm fan with intelligent semi-fanless operation
Product image gallery
About this product
Details & use
￭ Compact design with a depth of 140mm for easy integration ￭ High efficiency with 80 PLUS Platinum certification ￭ 100% modular cables ￭ 24/7 continuous power output with 40℃ operating temperature ￭ Class-leading single +12V rail ￭ Strict ±3% voltage regulation and low ripple & noise ￭ Ultra silent 120mm fan with intelligent semi-fanless operation
Technical specifications are provided by Taba Trading Expansion. Products are sold exclusively through authorized dealers. For availability, pricing, and orders, please contact the sales team.
Photo 1/2
Specifications
Technical specs
Performance & Compatibility
- Input Frequency Range
- 47 تا 63 هرتز
Design & Dimensions
- Cooling system
- Single 120mm silent fan
- Dimensions
- 86 × 140 × 150 mm
- Weight
- 2.54 kg
- Form factor
- ATX
Other specs
- MTBF
- 100,000 hours
- 12V
- 0.3 آمپر
- Combined 12V
- 70.9 آمپر
- Color
- Black (lead-free paint)
- 12-pin PCIe
- No
- Certification
- 80 PLUS Platinum
- 8-pin PCIe
- 4 pcs
- Efficiency
- 89%~92% at 20%~100% loading
- 3.3V
- 22 آمپر
- Cabling
- فول ماژولار
- Wattage
- 850 W
- Input voltage
- 90 تا 264 V
- 5V
- 22 آمپر
- 24-pin connector
- 1 pcs
- Operating temperature
- 0 تا 40 ° سانتی گراد
- 8-pin EPS
- 2 pcs
- 15-pin SATA
- 12 pcs
- 4-pin Molex
- 3 pcs
- FDD
- 1 PCS
- Protection
- Over current protection Over power protection Over voltage protection Short circuit protection Under voltage protection Over temperature protection
- Active PFC
- Yes
- Noise level
- 0 ~ 28 dBA
- LED color
- No
Key points
Why this product?
The standout features that make this model a strong choice for professional builds.
MTBF: 100,000 hours
Cooling system: Single 120mm silent fan
12V: 0.3 آمپر
Dimensions: 86 × 140 × 150 mm
